Trek
Price €3.799,00
Available colours
Battery options
Frame shape
DiamondLease this bike through your employer. Calculate the lease price per month
€
€
Please note: the stated lease and sales prices are indicative. The sales price of the (web)shop is leading for the final lease price.
Costs per month from
Specifications
+−
In general
Model year
2027
Rear wheel size
29
Front wheel size
29
Fork
Fork brand
Rockshox
Fork model
RockShox Recon Silver RL, Solo Air, Motion Control-Dämpfung, Lockout, konischer Gabelschaft, 42 mm Vorbiegung, Boost110, 15 mm Maxle Stealth-Achse, 120 mm Federweg
Stem
Stem brand
Bontrager
Stem model
Bontrager Rhythm Comp, 31,8 mm, 0 Grad, 50 mm Länge
Chain
Chain brand
Shimano
Chain model
Shimano Deore M6100, 12fach
Frame
Frame size
45
Frame type
Uni
Frame material
Aluminium
Frame size
XL
Gears
Gear type
Kettenschaltung
Gear brand
Shimano
Gear model
Shimano Deore M8200, langer Käfig
Number of gears
1
Tyres
Tyre brand
Bontrager
Tyre model
Bontrager Gunnison Elite XR, Tubeless-Ready, Drahtwulstkern, 60 TPI, 29 x 2.40
Pedals
Pedals brand
Ohne Markenzeichen
Pedals model
Nylon-Pedalfläche
Saddle
Saddle brand
Bontrager
Saddle model
Bontrager Commuter Comp
Wheels
Wheels model
Bontrager Kovee, Hohlkammerfelge, Tubeless Ready, 28-Loch, 23 mm Innenweite, Presta-Ventil // Bontrager Kovee, Hohlkammerfelge, Tubeless Ready, 32-Loch, 23 mm Innenweite, Presta-Ventil
Shimano TC500, Aluminium, Center Lock-Scheibenaufnahme, 110 x 15 mm Steckachse
Shimano TC500 Aluminium, Centerlock, 148x12 mm Steckachse // Shimano TC500, Aluminium, Center Lock-Scheibenaufnahme, 148 x 12 mm Steckachse
Headset
Headset brand
FSA
Headset model
FSA IS-2, 1 1/8" oben, 1,5" unten
Cassette
Cassette brand
Sunrace
Cassette model
SunRace CSMZ800 11-51, 12 speed // Shimano XT M8100, 10-51 Z., 12fach
Crankset
Crankset brand
Ohne Markenzeichen
Crankset model
FSA, Aluminium, 160 mm Kurbelarmlänge
Geometry
Trail
11.7
Offset
4.4
Wheelbase
125.9
Head angle
66.5
Frame reach
49
Frame stack
67.3
Top tube length
65.8
Seat tube angle
74.6
Chainstay length
46.1
Head tube length
14.3
Seat tube length
45
Stand over height
74.6
Bottom bracket drop
6.5
Bottom bracket height
31.5
Seatpost
Seatpost brand
TranzX
Seatpost model
TranzX JD-YSI34, 170 mm Hub, interne Zugführung, 31,6 mm, 500 mm Länge
Shifters
Shifters brand
Shimano
Shifters model
Shimano Deore M6200
Handlebar
Handlebar brand
Bontrager
Handlebar model
Bontrager Comp, Aluminium, 31,8 mm, 40 mm Rise, 780 mm Breite
Front brake
Front brake type
Scheibenbremse mit hydraulischer Steuerung
Front brake brand
Shimano
Front brake model
Hydraulische 4-Kolben-Scheibenbremse von Shimano, MT4100 Bremshebel, MT420 Bremssattel // Hydraulische 4-Kolben-Scheibenbremse von Shimano, MT4100 Bremshebel, MT420 Bremssattel // Shimano hydraulische Scheibenbremse, MT4100 Bremshebel, MT420 4-
Shimano RT64, Centerlock-Scheibenaufnahme, 203 mm // Shimano RT64, Centerlock-Scheibenaufnahme, 203 mm
Max. Bremsscheibendu
Seatpost clamp
Seatpost clamp brand
Ohne Markenzeichen
Seatpost clamp model
Bolt-on, 36,4 mm
Rear derailleur
Rear derailleur brand
Shimano
Rear derailleur model
Shimano Deore M8200, langer Käfig
Bar tape/Grips
Bar tape/Grips brand
Bontrager
Bar tape/Grips model
Bontrager XR Endurance Comp, mit Klemmung
Rear brake
Rear brake type
Scheibenbremse mit hydraulischer Steuerung
Rear brake brand
Shimano
Rear brake model
Hydraulische 4-Kolben-Scheibenbremse von Shimano, MT4100 Bremshebel, MT420 Bremssattel // Hydraulische 4-Kolben-Scheibenbremse von Shimano, MT4100 Bremshebel, MT420 Bremssattel // Shimano hydraulische Scheibenbremse, MT4100 Bremshebel, MT420 4-
Shimano RT64, Centerlock-Scheibenaufnahme, 203 mm // Shimano RT64, Centerlock-Scheibenaufnahme, 203 mm
Max. Bremsscheibendu
E-bike Specifications
+−
In general
E-bike type
Normal
Walk assist
Yes
spec_handle_control
Yes
Drivetrain brand
Bosch
spec_order_without_battery
No
spec_order_without_charger
No
spec_order_without_display
No
Engine
Engine brand
Bosch
Engine model
Bosch Performance Line CX (Europa und Asien-Pazifik: 25 km/h, USA und Rest der Welt: 32 km/h)
Charger
Charger brand
Bosch
Charger model
Bosch Standardladegerät 4 A, 230 V, Smart System
Display
Display brand
Bosch
Display model
Bosch Purion 200
spec_operation_type
Lenker (zentral)
